Metalized Polypropylene Packaging

We are looking for bulk enquiries for Metallized Polypropylene Capacitor, MPA Series axial capacitors etc. Metallized Capacitors are used in the designing of circuits of electronic and electric appliances. They are used for DC pulsation, pulse, and AC voltage reduction in instruments, meters and TV sets.

Category Axial film capacitors

Product Description

Feature:

1.Non-inductive construction and self-healing
2.Low DF and high IR
3.High capacitance value available and compact size

Application:
1.Coupling decoupling by-passing and timing circuit
2.Automatic control system, communication equipment
3.Charging/discharging, lighting, noise suppression and frequency

Specifications:

Dielectric: Polypropylene film

Electrodes: Vacuum evaporated metal

Coating: Out wrapped with Mylar tape and ends sealed with epoxy resin

Leads: Axial leads of tinned wire

Reference standard: IEC 384-16 GB 10190-1988

Climatic catalogue: 40/85/21

Capacitance versus rated voltage (Ur): 0.01UF-6.8UF/100VDC, 0.01UF-6.8UF/250VDC, 0.01UF-1.5UF/400VDC, 0.01UF-1.0UF/630VDC

Capacitance tolerance: M=±20%, K=±10%, J=±5%

Dissipation factor (tangent of loss): DF ≤0.1% (at 20°C, 1kHz)

Metalized Capacitors are used in the designing of circuits of electronic and electric appliances. Metallized Polypropylene film capacitors are available with different values of general and value ratings. They are used for DC pulsation, pulse, and AC voltage reduction in instruments, meters, TV sets and household electrical appliances.
